AUDIO VIDEO SURROUND RECEIVER

VR-6050

KRF-V7060D

KRF-V6060D

INSTRUCTION MANUAL

KENWOOD CORPORATION

This instruction manual is for some models. Model availability and features (functions) may differ depending on the country and sales area.

About the supplied remote control

Compared to standard remote controls, the remote control supplied with this receiver has several operation modes. These modes enable the remote control to control other audio/video components. In order to effectively use the remote control it is important to read the operating instructions and obtain a proper understanding of the remote control and how to switch its operation modes (etc.).

Using the remote control without completely understanding its design and how to switch the operation modes may result in incorrect operations.

Caution : Read this page carefully to ensure safe operation.

Units are designed for operation as follows.

For the United Kingdom

Factory fitted moulded mains plug

1.The mains plug contains a fuse. For replacement, use only a 13Amp ASTA-approved(BS1362) fuse.

2.The fuse cover must be refitted when replacing the fuse in the moulded plug.

3.Do not cut off the mains plug from this equipment. If the plug fitted is not suitable for the power points in your home or the cable is too short to reach a power point, then obtain an appropriate safety approved extension lead or adapter, or consult your dealer.

If nonetheless the mains plug is cut off, remove the fuse and dispose of the plug immediately, to avoid a possible shock hazard by inadvertent connection to the mains supply.

IMPORTANT: The wires in the mains lead are coloured in accordance with the following code:

Blue : Neutral

Brown : Live

* AC voltage selection

The AC voltage selector switch on the rear panel is set to the voltage that prevails in the area to which the unit is shipped. Before connecting the power cord to your AC outlet, make sure that the setting position of this switch matches your line voltage. If not, it must be set to your voltage in accordance with the following direction.

AC voltage selector switch

Note:

Our warranty does not cover damage caused by excessive line voltage due to improper setting of the AC voltage selector switch.

Do not connect those leads to the earth terminal of a three-pinplug.

Safety precautions

WARNING :

TO PREVENT FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLEPARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

THE LIGHTNING FLASH WITH ARROWHEAD SYMBOL, WITHIN AN EQUILATERAL TRIANGLE, IS INTENDED TO ALERT THE USER TO THE PRESENCE OF UNINSULATED “DANGEROUS VOLTAGE” WITHIN THE PRODUCT’S ENCLOSURE THAT MAY BE OF SUFFICIENT MAGNITUDE TO CONSTITUTE A RISK OF ELECTRIC SHOCK TO PERSONS.

THE EXCLAMATION POINT WITHIN AN EQUILATERAL TRIANGLE IS INTENDED TO ALERT THE USER TO THE PRESENCE OF IMPORTANT OPERATING AND MAINTENANCE (SERVICING) INSTRUCTIONS IN THE LITERATURE ACCOMPANYING THE APPLIANCE.

Before applying the power

Contents

Caution : Read the pages marked carefully to ensure safe operation.

Remote control unit (RC-R0725)(KRF-V7060D)

Remote control unit (RC-R0726)(KRF-V6060D)

Unpacking

Unpack the unit carefully and make sure that all accessories are present.

For KRF-V6060D(For the U.K. only)

*AC plug adaptor (2)

*Use to adapt the plug on the power cord to the shape of the wall outlet. (Accessory only for regions where use is necessary.)

If any acccessories are missing, or if the unit is damaged or fails to operate, notify your dealer immediately. If the unit was shipped to you directly, notify your shipper immediately. Kenwood recommends that you retain the original carton and packing materials in case you need to move or ship the unit in the future.

Keep this manual handy for future reference.

3 EN

Before applying the power

How to use this manual

This manual is divided into four sections, Preparations, Operations, Remote Control, and Additional Information.

Preparations

Shows you how to connect your audio and video components to the receiver and prepare the surround processor.

Since this receiver works with all your audio and video components, we will guide you in setting up your system to be as easy as possible.

Operations

Shows you how to operate the various functions available on the receiver.

Remote Control

Shows you how to operate other components using the remote control, as well as a detailed explanation of all remote control operations. Once you have registered your components with the proper setup codes, you’ll be able to operate both this receiver and your other AV components (TV, VCR, DVD player, CD player, etc.) using the remote control supplied with this receiver.

Additional Information

Shows you additional information such as “In case of difficulty” (troubleshooting) and “Specifications”.

For the U.S.A.

FCC WARNING

This equipment may generate or use radio frequency energy. Changes or modifications to this equipment may cause harmful interference unless the modifications are expressly approved in the instruction manual. The user could lose the authority to operate this equipment if an unauthorized change or modification is made.

NOTE:

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment may cause harmful interference to radio communications, if it is not installed and used in accordance with the instructions. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

–– Reorient or relocate the receiving antenna.

–– Increase the separation between the equipment and receiver.

–– Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

–– Consult the dealer or an experienced radio / TV technician for help.

Maintenance of the unit

When the front panel or case becomes dirty, wipe with a soft, dry cloth. Do not use thinner, benzine, alcohol, etc. for these agents may cause discoloration.

In regard to contact cleaner

Do not use contact cleaners because it could cause a malfunction. Be specially careful not to use contact cleaners containing oil, for they may deform the plastic component.

Memory back up function

Please note that the following items will be deleted from the unit's memory if the power cord is disconnected from the AC outlet for approximately 1 day.

For the U.S.A.

Note to CATV system installer

This reminder is provided to call the CATV system installer's attention to Article 820-40of the NEC that provides guidelines for proper grounding and, in particular, specifies that the cable ground shall be connected to the grounding system of the building, as close to the point of cable entry as practical.

As an ENERGYSTAR® Partner, Kenwood Corporation has determined that this product meets theENERGYSTAR® guidelines for energy efficiency. This product can save energy. Saving energy re-

duces air pollution and lowers utility bills.

Before applying the power

Special features

True home theater sound

This receiver incorporates a wide variety of surround modes to bring you maximum enjoyment from your video software. Select a surround mode according to your equipment or the software you are going to play and enjoy! ¶

DSP surround modes

The DSP (Digital Signal Processor) used for this receiver incorporates a variety of high quality adjustable sound fields, like “ARENA”, “JAZZ CLUB”, “THEATER”, “STADIUM” and “DISCO”. It is compatible with almost any kind of program source.

Dolby Digital and Dolby Digital EX

The DOLBY DIGITAL mode lets you enjoy full digital surround from software processed in the Dolby Digital format. Dolby Digital provides up to 5.1 channels of independent digital audio for better sound quality and more powerful presence than conventional Dolby Surround.

As for Dolby Digital EX, it creates six full-bandwidthoutput channels from the 5.1 channel sources. This is done using a matrix decoder that derives three surround channels from the two in the original recording. For best results, Dolby Digital EX should be used with movie soundtracks recorded with Dolby Digital Surround EX.

Dolby PRO LOGIC II

Dolby PRO LOGIC II, whilst totally compatible with its predecessor PRO LOGIC, provides greater advantages in surround sound. It allows the user to enjoy the conventional stereo or Dolby Surround with a convincing “5.1 like” presentation. PRO LOGICII offers special features for controlling the overall spatial, dimensionality and frontal sound field imaging. PRO LOGICII produces an impressive surround sound from video software marked andthree-dimensionalspace from music CD. When listening to music, you will be able to enjoy the experience of sheer STEREO surround sound.

DTS

DTS (Digital Theater System) is a 5.1 channel digital audio format that provides five full-spectrumchannels and onelow-frequency(subwoofer) channel for unprecedented clarity, optimum channel separation and a (wide) dynamic range.

In the DTS mode, the 5.1 channel digital input from a DTS CD, LD or DVD disc (carrying the “DTS” marking) can be played in Digital Surround.

Important:

When a DTS disc is played on a CD, LD or DVD player, noise may be output from the analog output. It is recommended that you connect the digital output of the player to the digital input of this unit.

DVD 6-channelinput

If you own a DVD player equipped with 6-channeloutput, this receiver allows you to obtain the full surround sound impact of DVD source material featuringmulti-channelencoding. Since the source signals are digital and each channel is input independently, the resulting ambience is far superior to what can be achieved with conventional surround sound systems.

ACTIVE EQ

ACTIVE EQ mode will produce a more dynamic sound quality in any condition. You can enjoy a more impressive sound effect when ACTIVE EQ is turned on during Dolby Digital and DTS playback.

SPEAKER EQ

The SPEAKER EQ function will automatically detect the various features of each speaker and effectively creates a stereoscopic sound effect.

Universal IR (InfraRed) remote control

In addition to the basic receiver, the remote control supplied with this receiver can also operate almost all of your remote controllable audio and video components. Just follow the simple setup procedure to register the components you have connected.

RDS (Radio Data System) tuner (For the U.K. only)

The receiver is equipped with an RDS tuner that provides several convenient tuning functions: RDS Auto Memory, to automatically preset up to 40 RDS stations broadcasting different programs; station name display, to show you the name of the current broadcast station; and PTY search to let you tune stations by program type.

PTY (Program TYpe) search (For the U.K. only)

Tune the stations by specifying the type of program you want to hear.

SRS Circle Surround II ™ improves on its predecessorCS-5.1™resulting in theCS-6.1™system, enabling you to listen to realistic, multichannel, surround sound playback from a stereo source or conventionalsurround-encodedvideo source. You already enjoy listening to Dolby digital sound/DTSmulti-channelsound with yourmulti-speakers.Now you can listen to audio CDs, MDs, Broadcast and Home Theater using yourmulti-speakers.You will discover a new type of sound through SRS Circle SurroundII .

Names and functions of parts

Main unit

For KRF-V7060Dand

KRF-V6060D(For the U.K. only)

Standby mode

While the standby indicator is lit, a small amount of power is supplied to the system to back up the memory. This is called standby mode. Under the condition, the system can be turned ON by remote control unit.

Connection at POWER ON/OFF key (for KRF-V7060D/V6060D)

The power in this equipment will not be completely cut off from the AC wall outlet when the main switch is turned OFF.

Names and functions of parts

Remote control unit (RC-R0725)(KRF-V7060D)and(RC-R0727)(VR-6050/KRF-V6060D)

This remote control unit can be use not only for Kenwood products but also for other non-Kenwoodproducts by setting the appropriate manufacturer’s setup codes. fi

™ENTER £

^

&

*

(

)

¡

™

£

¢

∞

§

¶

•

ª

ºIf the name of a function is different on

⁄ the receiver and on the remote control, the name of the remote control key in

¤this manual is indicated in parentheses.

Setting up the system

Make connections as shown in the following pages.

When connecting the related system components, be sure to refer to the instruction manuals supplied with the components you are connecting.

Do not connect the power cord to a wall outlet until all connections are completed.

Notes

1.Be sure to insert all connection cords securely. If their connections are imperfect, sound may not be produced or there will be noise inference.

2.Be sure to remove the power cord from the AC outlet before plugging or unplugging any connection cords. Plugging/unplugging connection cords without disconnecting the power cord can cause malfunctions and may damage the unit.

3.Do not connect power cords from components whose power consumption is larger than what is indicated on the AC outlet at the rear of this unit.

Analog connections

Audio connections are made using RCA pin cords. These cables transfer stereo audio signal in an “analog” form. This means the audio signal corresponds to the actual audio of two channels. These cables usually have 2 plugs on each end, one red for the right channel and one white for the left channel. These cables are usually packed together with the source unit, or are available at your local electronics retailer.

Microcomputer malfunction

If operation is not possible or an erroneous display appears, even though all connections have been made properly, reset the microcomputer referring to “In case of difficulty”. ‚

CAUTION

Be sure to adhere to the following, or proper ventilation will be blocked causing damage or fire hazard.

•Do not place any objects impairing heat radiation onto the top of the unit.

•Leave some space around the unit (from the largest outside dimension including projection) equal to or greater than, shown below.

Top panel : 50 cm Side panel : 10 cm Back panel : 10 cm

Input mode settings

CD/DVD, VIDEO 2 andDVD/6CH inputs each include jacks for digital audio input and analog audio input.

The initial factory settings for audio signal playback for CD/DVD,

DVD/6CH and VIDEO 2 are full auto.

To use the analog audio input for playback instead (if, for example, you have connected a VCR to the VIDEO2 input), you must set the input mode for the corresponding input to the analog mode.

After completing connections and turning on the receiver, follow the steps below.

INPUT MODE

Input Selector

1Use the Input Selector keys to select CD/DVD, VIDEO 2 or DVD/6CH.

2Press the INPUT MODE key.

Each press switches the setting as follows:

In DTS play mode

1FULL AUTO (digital input, analog input) 2DIGITAL MANUAL (digital input)

In CD/DVD, VIDEO 2, DVD/6CH play mode

1FULL AUTO (digital input, analog input) 2DIGITAL MANUAL (digital input)

3 6CH INPUT (DVD/6CH input)

4 ANALOG (analog input)

Digital input:

Select this setting to play digital signals from a DVD, CD, or LD player.

Analog input:

Select this setting to play analog signals from a cassette deck, VCR, or record player.

Auto detect:

In “FULL AUTO” mode (AUTO DETECT indicator light up), the receiver detects the digital or analog input signals automatically. Priority is given to digital signal during input mode selection. The receiver will select the input mode and listening mode automatically during playback to match the type of input signal (Dolby Digital, PCM, DTS) and the speaker setting. The OPTICAL and COAXIAL indicator on the display will light up when digital signal is detected. If the input signal is analog, the ANALOG indicator will light up.

To keep the receiver set to the currently selected listening mode, use the INPUT MODE key to select “DIGITAL MANUAL” (manual sound). However, even when this setting is selected, there may be cases in which the listening mode is selected automatically to match a Dolby Digital source signal depending on the combination of listening mode and source signal.

If the INPUT MODE key is pressed quickly, sound may not be produced. Press the INPUT MODE key again.

Setting up the system

Connecting audio components

Shape of AC outlets

U.S.A. and Canada

U.K.

Australia

Other countries

SYSTEM CONTROL

jacks &

To AC wall outlet

IN

L

R

AUX

[For VR-6050andKRF-V6060D(except for the U.K.)]

OUT Cassette deck or

MD recorder

IN

OUT

CD or DVD player

OUT

Moving coil (MC) cartridge record player cannot be used directly from the receiver unit. It can only be used when another equalizer amplifier is connected.

10 EN

Setting up the system

Connecting video components

About the S VIDEO jacks

S VIDEO

Use the S VIDEO jacks to make connections to video components with S VIDEO IN/OUT jacks.

•If you use the S VIDEO jacks to connect your video playback components, be sure to use theS VIDEO jacks when connecting your monitor and video recording components.

A video component with digital audio outputs should be connected to the VIDEO 2 jacks.

Setting up the system

Digital connections

The digital in jacks can accept DTS, Dolby Digital, or PCM signals. Connect components capable of outputting DTS, Dolby Digital, or standard PCM (CD)

COAXIAL OPTICAL

CD/DVD

VIDEO 2

DVD/

6CH

DIGITAL IN

COAXIAL DIGITAL OUT (AUDIO)

RF digital demodulator (DEM-9991D)(sold separately)

DOLBY DIGITAL RF

OUT (AUDIO)

Optical fiber OPTICAL DIGITAL OUT (AUDIO) cable

CD or DVD player

COAXIAL DIGITAL OUT (AUDIO)

Component with DTS,

Dolby Digital, or PCM

COAXIAL DIGITAL OUT

Connect the video signal and analog audio signals to the VIDEO 2 jacks. (See “Connecting video components”.)

!

PCM OUT

LD player

To connect an LD player with a DIGITAL RF OUT, connect the LD player to the KENWOOD RF digital demodulator (DEM-9991D).Next, connect the DIGITAL OUT jacks of the demodulator to the DIGITAL IN jacks of the receiver.

Connect the video signal and analog audio signals to the VIDEO 2 jack. (See “Connecting video components”.)

Setting up the system

Connecting a DVD player (6-channelinput)

Setting up the system

Connecting the speakers

Front Speakers A

Powered

subwoofer

Center

Speaker

SPEAKERS (8-16)

+

-

R L R

Surround Speakers

(Be sure to connect both surround speakers)

Use the FRONT SPEAKERS B terminals if you want to connect a second front speaker system.

Setting up the system

Connecting the terminals

Connection of banana plugs (For the U.S.A. and Canada)

•Sound will not be heard if the speaker terminal is not fully secured.

•Never short circuit the + and – speaker cords.

•If the left and right speakers are connected inversely or the speaker cords are connected with reversed polarity, the sound will be unnatural with ambiguous acoustic imaging. Be sure to connect the speakers correctly.

Speaker impedance

After confirming the speaker impedance indications printed on the rear panel of the receiver, connect speakers with matching impedance ratings. Using speakers with a rated impedance other than that indicated on the rear panel of the receiver could result in malfunctions or damage to the speakers or receiver.

Speaker placement

Center speaker

Surround

back speaker

Front speakers : Place at the front left and right of the listening position. Front speakers are required for all surround modes.Center speaker : Place front and center. This speaker stabilizes the sound image and helps recreate sound motion. Required for surround playback.

Surround speakers : Place at the direct left and right, or slightly behind, the listening position at even heights, approximately 1 meter above the ears of the listeners. These speakers recreate sound motion and atmosphere. Required for surround playback.

Subwoofer : Reproduces powerful deep bass sounds.

Surround back speaker : Place the speaker directly at the rear of the listening position. The optimum position depends mainly on the room condition.

• Although the ideal surround system consists of all the speakers listed above, if you don't have a center speaker or a subwoofer, you can divide those signals between the available speakers in the speaker settings steps to obtain the best possible surround reproduction from the speakers you have available. *

Channel space switching

(Except for the U.S.A., Canada, U.K., and Australia)

The space between radio channels has been set to the one that prevails in the area to which the system is shipped. However, if the current channel space setting does not match the setting in the area where the system is to be used, for instance when you move from area 1 or area 2 shown in the following table or vice versa, proper reception of AM/FM broadcasts cannot be expected. In this case, change the channel space setting in accordance with your area by referring to the following table.

Turn the power OFF by pressing the POWER key before moving the switch level. Move switch lever to match your area with a small screwdriver or other pointed tool, then turn the power on again.

Setting up the system

Connecting to the AV AUX jacks

The AV AUX jacks are convenient for connection of video components such as a camcorder or a video game.

AV AUX

S VIDEO cord

Connecting the antennas

AM loop antenna

The supplied loop antenna is for use indoors. Place it as far as possible from the receiver, TV set, speaker cords and power cord, and adjust the direction for best reception.

AM antenna terminal connections

FM indoor antenna

The supplied indoor antenna is for temporary use only. For stable signal reception we recommend using an outdoor antenna. Disconnect the indoor antenna when you connect one outdoors.

FM antenna terminal connections

Insert cord.

FM outdoor antenna

Lead the 75Ω coaxial cable connected to the FM outdoor antenna into the room and connect it to the FM 75Ω terminal.

Camcorder, other VCR,

S VIDEO OUT video game, digital camera,AUDIO OUT or portable MD player

• To select the source connected to the AV AUX jacks press AV AUX key. ¡

•When you connect the audio source such as the MD player, you do not need to connect the video cable.

•When you connect the unit and the component with the S VIDEO cord, you can get better picture quality.

Setting up the system

Connecting the system control

Connecting system control cords after connecting a KENWOOD audio component system lets you take advantage of convenient system control operations.

This unit is compatible only with the [SL-16]mode. The system control operation is not available if the unit is connected in the [XS8], [XS], or [XR] connection mode.

If your component has the mode select switch, set the connected components to the [SL16] mode.

SYSTEM CONTROL

SYSTEM CONTROL cord

• You may connect the system control cord to either the up or down jack.

EXAMPLE: [SL16] mode connections

The underlined portion represents the setting of the system control mode.

•In order to take advantage of the system control operations, the components must be connected to the correct jacks. To use a CD player it must be connected to the CD jacks. To use a cassette deck (or MD recorder) it must be connected to the MD/TAPE jacks. When using more than one CD player (etc.) only the one connected to the specified jacks may be connected for system control.

•Some CD players and cassette decks are not compatible with the [SL16] system control mode. Do not make system connections with equipment that is not [SL16] compatible.

•Some MD players are not system control compatible. You cannot make system control connections to this kind of equipment.

Notes

1.[SL16] equipment cannot be combined with [XR], [XS], and [XS8] equipment for system operations. If your equipment consists of this kind of combination, please do not connect any system control cords. Even without system control cords, normal operations can be carried out without effecting performance.

2.Do not connect system control cords to any components other than those specified by KENWOOD. It may cause a malfunction and damage your equipment.

3.Be sure the system control plugs are inserted all the way in to the system control terminals.

SYSTEM CONTROL OPERATIONS

Remote Control

Lets you operate this unit with the system remote supplied with the receiver.

Automatic Operation

When you start playback from a source component, the input selector on this unit switches to that component automatically.

Synchronized Recording

Lets you synchronize recording with the start of playback when recording from CD, MD or analog discs.

Preparing the remote control

Loading the batteries

3 Close the cover.

• Insert two AA-size(R6) batteries as indicated by the polarity markings.

Operation

When the STANDBY indicator is lit, the power turns ON when you press thePOWERkey on the remote control. When the power comes ON, press the key you want to operate.

6 m

POWER

Infrared ray system

•When pressing more than one remote control key successively, press the keys securely by leaving an interval of 1 second or more between keys.

Notes

1.The supplied batteries may have shorter lives than ordinary batteries due to use during operation checks.

2.When the remote-controllabledistance gets shorter than before, replace both batteries with new ones.

3.Placing the remote sensor in direct sunlight, or in direct light from a high frequency fluorescent lamp may cause a malfunction.

In such a case, change the location of the system installation to prevent malfunction.

Registering setup codes for KENWOOD audio components

If you own remote controllable KENWOOD audio components that are not compatible with system control, registering the setup code enables you to control those components using the remote control supplied with this unit (without connecting system control cords). To register setup codes for your remote controllable KENWOOD audio

components, see “Registering setup codes for other components”.

‹

Preparing for surround sound

Speaker settings

To enable you to obtain optimum enjoyment from the receiver’s listening modes, make sure to complete the speaker settings (subwoofer, front, center, and surround speakers) as described below.

POWER

ON/STANDBY

(VR-6050) / ON/STANDBY

(KRF-V7060D/V6060D)SETUP MULTI CONTROL

POWER ON/OFF

(KRF-V7060D/V6060D)

POWER

SET UP

Joystick

(MULTI CONTROL 5/∞, DOWN2 / UP3)

1Turn on the power to this receiver by pressing the POWER ON/STANDBY (forVR-6050)or POWER ON/OFF and ON/ STANDBY(KRF-V7060D/V6060D)or POWERkey.

2Press the SETUP key to enter the SET UP mode and press M/? keys or Joystick (2/3) for the following displays.

1 SP SETUP2 TEST TONE

3 SP DISTANCE

4 DISP MODE

5 EXIT

The flow of the SET UP is as follows:

SP SETUPTEST TONESP DISTANCEDISP MODEEXIT

3Select a speaker system.

1 Select the SP SETUP and press the SETUP key again so that the subwoofer setting indication “SUBW ON” appears.

2Use the MULTI CONTROL knob or Joystick (5/∞) to select the appropriate subwoofer setting.

1SUBW ON : Subwoofer setting mode to the receiver is ON.

2SUBW OFF : Subwoofer setting mode to the receiver is OFF.

•The initial setting is “SUBW ON”.

•When the setting “SUBW OFF” is selected, the front speakers are automatically set to “FRNT LARGE” and the procedure skips to step 6.

Before step 6, press the SETUP key to accept the setting.

•When subwoofer output sound is required, select “FRNT NORMAL” or select both “FRNT LARGE” and “SW RE-MIXON”.

3Press the M key or Joystick (3) to accept the setting.

• The front speakers setting indication “FRNT” appears.

4Use the MULTI CONTROL knob or Joystick (5/∞) to select the appropriate front speakers setting.

•For “FRNT LARGE” selection, no sound will be heard from subwoofer speaker even when it is set to ON. However, if you select “SW RE-MIXON” when subwoofer is selected, you will be able to hear sound from the subwoofer.

When in STEREO mode, the sound goes directly to front speaker.

5Press the M key or Joystick (3) to accept the setting.

• The center speaker setting indication “CNTR” appears.

6Use the MULTI CONTROL knob or Joystick (5/∞) to select the appropriate center speaker setting.

If you selected “LARGE” as the front speakers setting,

1CNTR LARGE : A large center speaker is connected to the receiver.

2 CNTR NORMAL : An average size center speaker is

If you selected “NORMAL” as the front speakers setting,

1CNTR ON : Center speaker setting mode to the receiver is ON.

2CNTR OFF : Center speaker setting mode to the receiver is OFF.

7Press the M key or Joystick (3) again to accept the setting.

• The surround speaker setting indication “SURR” appears.

8Use the MULTI CONTROL knob or Joystick (5/∞) to select the appropriate surround speaker setting.

If you selected “LARGE” as the center speaker setting,

1SURR LARGE : Large surround speakers are connected to the receiver.

2 SURR NORMAL : Average size surround speakers are

Preparing for surround sound

If you selected other than “LARGE” as the center speaker setting,

•When the setting “SURR OFF” is selected, the procedure skips to step #.

9Press the M key or Joystick (3) again to accept the setting.

• The surround speaker setting indication “SB” appears.

0Use the MULTI CONTROL knob or Joystick (5/∞) to select appropriate surround back speaker setting.

If you selected “LARGE” as the surround speaker setting,

4Adjust the speaker volume level.

From your usual listening position, adjust the volume levels. The volume levels from each speaker should be the same.

1 Press the M/? keys or Joystick (2/3) to select TEST TONE.

2 Press the SETUP key for the following displays:

1 T.TONE AUTO

2 T.TONE MANUAL

3The selection of AUTO/MANUAL TEST TONE is done by the MULTI CONTROL knob or Joystick (5/∞).

Press the SETUP key again to begin TEST TONE.

Use the MULTI CONTROL knob or Joystick (5/∞) to adjust the volume level of the test tone output from the speaker channel to be adjusted.

For AUTO selection, the first test tone is heard from the front left speaker for 2.5 seconds. The next test tone is heard from the speakers in the following sequence for 2 seconds each.

LEFTCNTRRIGHT

SUBWSLSBSR

The channel indication blinks while the test tone is being output.

If you selected “NORMAL” as the surround speaker setting,

1SB ON : Surround back speaker setting mode to the receiver is ON.

2SB OFF : Surround back speaker setting mode to the receiver is OFF.

!Press the M key or Joystick (3) again to accept the setting and “SURR:MIX” appears.

•Surr:mix is when the SL and SR speakers signals are mixed to produce sound from the surround back speaker which would enable the listener to enjoy sound coming from the back.

@Use the MULTI CONTROL knob or Joystick (5/∞) to select the following.

1SURR:MIX ON : Surround mix setting mode to the receiver is ON.

2SURR:MIX OFF : Surround mix setting mode to the receiver is OFF.

•If surround back speaker is turned OFF, SURR:MIX setting is not visible and the procedure skips to step #.

#Press the M key or Joystick (3) again to accept the setting.

•The subwoofer re-mixsetting indication “SWRE-MIX”appears.

$Use the MULTI CONTROL knob or Joystick (5/∞) to select the appropriate subwooferre-mixsetting.

1SW RE-MIX ON : Subwooferre-mixsetting mode to the receiver is ON.

2SW RE-MIX OFF : Subwooferre-mixsetting mode to the receiver is OFF.

Kenwood Vr 6050 Receiver

•If subwoofer is turned OFF, subwoofer re-mixsetting is not visible.

%Press the SETUP key again to return to the main setup displays.

•The receiver enters the speaker volume level adjustment mode.

•In steps 4 and 5, indications appear only for the selected channels of the speakers that require adjusting.

•If you change the volume level settings for the speakers while listening to music, the settings referred to on this page are also

•If the speaker setting selects are OFF, the speaker level settings are reset.

For MANUAL selection, press the M/? keys or Joystick (2/3) each time to select the speaker channel.

4Press the SETUP key again.

• The test tone is turned off and return to the main setup displays.

5Input the distance to the speakers.

1 Press the M/? keys or Joystick (2/3) to select the SP

DISTANCE on setup displays and press the SETUP key again.

2Measure the distance from the listening position to each of the speakers.

Jot down the distance to each of the speakers.

3Use the M/? keys or Joystick (2/3) to select the speakers and the MULTI CONTROL knob or Joystick (5/∞) to adjust the distance to the front speakers.

The speaker indicator to be adjusted blinks.

Indication in feet Indication in meters

•The allowable setting range is 1 to 30 feet (0.3 to 9.0 m), adjustable in 1 foot (0.3 m) increments.

4 Repeat steps3to input the distance for each of the speakers.

Continued to next page

Preparing for surround sound

5Press the SETUP key again to return to main setup displays.

•The speakers you have selected should appear on the display. Confirm that all the speakers have been correctly selected.

6Select the display mode.

1 Press the M/? keys or Joystick (2/3) to select the DISP

MODE.

2 Press the SETUP key for the following displays:

3Use the MULTI CONTROL knob or Joystick (5/∞) to select the display mode.

4 Press the SETUP key again to accept the setting.

5 Use the M key or Joystick (3) to select EXIT.

6 Press the SETUP key to exit the SET UP mode.

Input level adjustment (analog sources only)

Dnx571tr Kenwood Owners Manual

If the input level of an analog source signal is too high, the CLIP indicator will blink to indicate the source signal. Adjust the input level.

1Use the Input Selector keys to select the source of which the input level you want to adjust.

• You can store a separate input level for each input source.

Kenwood Vr 6050 Problems

2Press the SOUND and M/? keys or Joystick (2/3) repeatedly until the “INPUT” indication appears.

3Use the MULTI CONTROL knob or Joystick (5/∞) to adjust the input level.

•The adjustment mode is displayed for approximately 8 seconds.

•The input level may be adjusted to any one of three settings: 0dB, -3dB,and-6dB.(The initial setting is 0dB.)

4 Press the SOUND key again to return to the input indication.

Kenwood Vr 6050 Owner's Manual Instructions
